PRODUCT DESCRIPTION
Curvy Welded Mesh Panels with smooth surface and firm structure is made of high quality low carbon steel, stainless steel and aluminum alloy steel. Its surface treatment includes PVC coated, PVC praying, hot-dipped galvanized and electric galvanized. The PVC coated and galvanized surfaces have good corrosion resistance and weather resistance, so it can provides a long service life.
Wire gauge:
2.5mm-6.0mm.
Mesh size:
50 x 100mm, 60 x 120mm, 75 x 150mm
Available in a range of sizes, colors.
Surface treatment:
plastic spraying, PVC coated, galvanized +PVC, powder coated.
Features:
long-distance protections, adjustable safety standards.
suitable for difficult grounds and topography.
good corrosion resistance, heat resistance.
high quality and good price.
SPECIFICATION
Specifications (H x W):
800, 1,000, 1,200, 1,500, 1,600, 1,800, 2,000 x 3,000mm; double layers 2,400, 2,600 x 2,800 x 3,000mm.
| Material | Q235 high quality low carbon steel wire |
| Wire diameter | 2.5 mm – 6.0 mm |
| Aperture | 50 mm X 100 mm, 60 mmx120mm, 75 mmx150mm, 80x160mm, 50X200mm. |
| Fence size | 800 x 3000 mm, 1000x3000mm, 1200x3000mm, etc |
| Post types | round column, square column |
| Surface treatment | plastic spraying, PVC coated, galvanized +PVC, powder coated |
| Color | green, black or as your requirement. |
| Accessories | rain hat, clip, bolt, chassis |
| Bending offered | one bending, two bending, three bending, four bending |
| If there is anything we can do for you, please contact us freely. | |
APPLICATION
Applications of curvy welded mesh panels:
Security cages
Security fencing
Metal fencing
Dog fencing
Animal enclosures
Aviaries
Bird cages
Pet hutches
Cat fences
Pond covers or protection
Garden fencing
It is widely applied for enclosing commercial grounds, lawn, road, freight yards, sport fields, airports and public districts.
